HID Aero™ X100 Door/Reader Interface Module

On-Board Access Point Control: Up to two access points with on-board IO
On-Board Reader Support: Up to four (OSDP multi-drop) or two (Wiegand) with on-board IO
Inputs: Seven supervised/unsupervised, standard EOL: 1k/1kΩ 1%, 1/4 watt
Outputs: Four Relays, Form-C with dry contacts
Relay Contact Rating: Two A @ 30 Vdc resistive
Input Voltage: 12 to 24 Vdc +/- 10%
Maximum Input Current: 1.5 A (340 mA excluding readers and USB)
Operating Temperature: 32 to 158 F (0 to 70 C)
Dimension: 6.46″” x 5.51″” x 1.02″” (164 mm x 140 mm x 26 mm)
